Drying herbs in a microwave machine is a quick and efficient method to preserve their flavors and extend their shelf life. No matter drying herbs , herbal slice, or pharma insect etc.
Microwave Machine Advantage in Herbs Pharma Industry
Drying herbs in a microwave oven is a quick and efficient method to preserve their flavors and extend their shelf life;
1. Microwave energy can evaporate water rapidly, drying fast, high efficiency, low cost;
2. Drying herbs in microwave machine compared to other traditional drying , can preserve the color, flavors & nutrition; which is also applicated in Spices industry;
3. Microwave drying herbs also can kill inside insect eggs & bacteria which can extend herbs shelf life; or sterilize the herbs.
Herbs Pharma Microwave Machine Application
1.Drying kinds of herbs in microwave, it can dry fast, but preserve their flavor, nutrition such as Parsley, rosemary, cilantro, oregano, sage, thyme etc.
2.Drying kind of herbal slices, 50% faster than normal heating, such as Astragalus, angelica, ginseng, aconite, habitat etc.
3.Drying kinds of insects, which can be used in pharma industry, such as Tenebrio molitor, barley pest, hermetia illucens.
4.Sterilize Pharma liquid, especially liquid type medicine.
Technical Specifications
Machine Model | GS-20HMV | GS-40HMV | GS-60HMV | GS-100HMV | GS-200HMV |
Work Frequency | 2450±50MHZ | 2450±50MHZ | 2450±50MHZ | 2450±50MHZ | 2450±50MHZ |
Rated Apparent Power | ≤25KW | ≤50KW | ≤75KW | ≤120KW | ≤240KW |
Output Power | ≥20KW | ≥40KW | ≥60KW | ≥100KW | ≥200KW |
Dehydration Capacity | 16-20kg/hour | 30-40kg/hour | 48-60kg/hour | 80-100kg/hour | 160-200kg/hour |
Work Process Temperature | 70-200℃ | 70-200℃ | 70-200℃ | 70-200℃ | 70-200℃ |
Cooling Type | Water Cool/Air Cool | ||||
Work Time | 24h Continuously Work | ||||
Feeding Inlet Height | 40-100mm | ||||
Belt Height | 60-1000mm | ||||
Belt Running Speed | 0-4.5m/min or Customized | ||||
Belt Width | 500±100mm | 800±100mm | 800±100mm | 1000±100mm | 1200±100mm |
Belt Material | Teflon Material or Customized | ||||
Size | 8640×1220×2200mm | 10960×1500×2200mm | 13200×1500×2200mm | 15600×1700×2200mm | 22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request.
We are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch microwave oven for lab
use or for small capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma industry etc. We have
more than 10 years experience on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam, Indonesia, Pakistan,
Philippines, Brazil, Egypt, Czech, Singapore, Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
