Microwave Dryer for Herbs & Pharma Industry

Drying herbs in a microwave machine is a quick and efficient method to preserve their flavors and extend their shelf life. No matter drying herbs , herbal slice, or pharma insect etc.

EMAIL


Microwave Machine Advantage in Herbs Pharma Industry

Drying herbs in a microwave oven is a quick and efficient method to preserve their flavors and extend their shelf life;

1. Microwave energy can evaporate water rapidly, drying fast, high efficiency, low cost;

2. Drying herbs in microwave machine compared to other traditional drying , can preserve the color, flavors & nutrition; which is also applicated in Spices industry;

3. Microwave drying herbs also can kill inside insect eggs & bacteria which can extend herbs shelf life; or sterilize the herbs.





Herbs Pharma Microwave Machine Application

1.Drying kinds of herbs in microwave, it can dry fast, but preserve their flavor, nutrition  such as Parsley, rosemary, cilantro, oregano, sage, thyme etc.

2.Drying kind of herbal slices, 50% faster than normal heating, such as Astragalus, angelica, ginseng, aconite, habitat etc.


3.Drying kinds of insects, which can be used in pharma industry, such as Tenebrio molitor, barley pest, hermetia illucens.

4.Sterilize Pharma liquid, especially liquid type medicine.


Technical Specifications


Machine Model

GS-20HMV

GS-40HMV

GS-60HMV

GS-100HMV

GS-200HMV

Work Frequency

2450±50MHZ

2450±50MHZ

2450±50MHZ

2450±50MHZ

2450±50MHZ

Rated Apparent Power

≤25KW

≤50KW

≤75KW

≤120KW

≤240KW

Output Power

≥20KW

≥40KW

≥60KW

≥100KW

≥200KW

Dehydration Capacity

16-20kg/hour

30-40kg/hour

48-60kg/hour

80-100kg/hour

160-200kg/hour

Work Process Temperature

70-200℃

70-200℃

70-200℃

70-200℃

70-200℃

Cooling Type

Water Cool/Air Cool

Work Time

24h Continuously Work

Feeding Inlet Height

40-100mm

Belt Height

60-1000mm

Belt Running Speed

0-4.5m/min or Customized

Belt Width

500±100mm

800±100mm

800±100mm

1000±100mm

1200±100mm

Belt Material

Teflon Material or Customized

Size

8640×1220×2200mm

10960×1500×2200mm

13200×1500×2200mm

15600×1700×2200mm

22560×1900×2200mm

Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request.

We are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch microwave oven for lab

use or for small capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma industry etc. We have

more than 10 years experience on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam, Indonesia, Pakistan,

Philippines, Brazil, Egypt, Czech, Singapore, Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
