Semi-automatic capsule filling machine

The automatic capsulefling machine is a new type of medical packaging machine with novel structure and beautiful shape.It is controlled by electrical appliances and pneumatics.tis equipped with electronic automatic counting device and speed contro device,which can complete the positioning,separation,filing and locking of capsules.Tight action,instead of manual filing, reduce labor intensity,improve production eficiency,accurate filing dose,inline with pharmaceutical hygiene requirements.
The machine is composed of a capsulefeeding head-turning separation mechanism,a medicine filing mechanism,a locking mechanism,a frequency conversion speed regulation mechanism,a pneumatic control and electrical control system,a protection device and other components,as well as vacuum pump and air pump accessories.
Both domestic and imported mechanism capsules can be applied,and the qualifed rate of finished products reaches more than 97%.


Overview

The automatic capsulefling machine is a new type of medical packaging machine with novel structure and beautiful shape.It is controlled by electrical appliances

and pneumatics.tis equipped with electronic automatic counting device and speed contro device,which can complete the positioning,separation,filing and locking

of capsules.Tight action,instead of manual filing, reduce labor intensity,improve production eficiency,accurate filing dose,inline with pharmaceutical hygiene requirements.

The machine is composed of a capsulefeeding head-turning separation mechanism,a medicine filing mechanism,a locking mechanism,a frequency conversion speed

regulation mechanism,a pneumatic control and electrical control system,a protection device and other components,as well as vacuum pump and air pump accessories.

Both domestic and imported mechanism capsules can be applied,and the qualifed rate of finished products reaches more than 97%.



Working sequence of capsule filling machine

Sowing---splitting---filling---tocking---out of the bag



Technical Parameters

Model 型号	CGN-208D 普通款	CGN-210D 水平款		CGN-212S 双播囊
Voltage电压	220V/380V-50HZ
Power功率	4KW
Yield(kg/h)产量	1-2万粒/小时	1.5-2.5万粒/小时		2-4万粒/小时
Applicable capsule适用胶囊	00#、0#、1#、2#、3#、4#、5# 机制标准胶囊
Filler填充剂型	Non-sticky powders and small granules不带粘性的粉剂、小颗粒剂
Air pressure空气压力	0.03(m³/min)0.7Mpa
真空泵Vacuum pump	40m³/h
Dimensions(mm)尺寸	1140x700x1630mm		1300x700x1650mm
Weight(kg)重量	300	350		400
00# 模具一盘 300粒;0# 模具一盘 360粒;1#、2#、3#、4# 模具一盘 420粒 00 # mold a plate of 300 tablets;0 # mold a plate of 360 tablets; 1 #, 2 #, 3 #, 4 # mold a plate of 420 tablets
